The guillotine shear machine is one of the forging and pressing machines and it is widely used in our life.This article will take you through some of the basics of the guillotine shear machine, including Classification,Usage and Working principle of the guillotine shear machine
The following knowledge points are listed below:
Classification of the guillotine shear machine
Guillotine shear machine for special purpose
Multi-purpose guillotine shear machine
Usage of the guillotine shear machine
Working principle of the guillotine shear machine
The guillotine shear machine is a machine for reciprocating straight-line motion of shear plates with one blade relative to another.By means of a moving upper blade and a fixed lower blade, reasonable blade clearance is used to apply shear force to various thickness of the metal plate, so that the plate according to the size of the required fracture separation.The guillotine shear machine is one of the forging and pressing machines.The products are widely used in aviation, light industry, metallurgy, chemical industry, construction, shipping, automobile, electric power, electrical appliances, decoration and other industries to provide the required special machinery and complete sets of equipment.
Guillotine shear machine for special purpose
(1) cold bending forming line guillotine shear machine: for example, special shearing machine configured on production lines such as cold bending of car longitudinal beam, car side baffle production line, color steel plate forming line, etc.;
(2) guillotine shear machine of steel structure production line: it is mainly used to complete the shearing process of Angle steel and h-beam automatic production line.
(3) guillotine shear machine: it is a high-speed shearing machine designed to meet the requirements of fast shearing speed of the production line on the flat plate uncoiling line. The thick plate line is mostly hydraulic high-speed shearing machine, and the thin plate line is equipped with pneumatic shearing machine.High speed line with flying shear, continuous production, high efficiency.
(4) guillotine shear machine: the upper and lower blades of the guillotine shear machine are at the same Angle. Generally, the upper blade is inclined, and its inclination Angle is generally 1° to 6°.The shearing force of inclined edge shears is smaller than that of flat edge shears, so the power of the motor and the weight of the whole machine are greatly reduced.
(5) flat blade guillotine shear machine: good shear quality, small distortion, but large shear force, high energy consumption.More mechanical transmission.The upper and lower blades of the shears are parallel to each other.According to its cutting mode can be divided into upper - cut and lower - cut.
Multi-purpose guillotine shear machine
1) guillotine shear machine: you can shear the plates and cut the profiles, which is mainly used in the blanking process;
2) guillotine shear machine: two processes of shearing and bending can be performed on the same machine.
The guillotine shear machine shall be able to ensure the straightness and parallelism of the shear plane of the sheared sheet material, and minimize the distortion of the sheet material to obtain high-quality workpiece.The upper blade of the shears is fixed on the tool rest and the lower blade is fixed on the work table.The work table is installed with a supporting ball, in order to facilitate the plate material in the above slide without being scratched.The rear stop is used for the positioning of the plate, and the position is adjusted by the motor.The pressure cylinder is used to compress the sheet metal to prevent it from moving during shearing.The guardrail is a safety device to prevent industrial accidents.The return journey is generally by nitrogen, the speed is fast, the impact is small.
I hope this article has helped you understand the guillotine shear machine. If you happen to need the guillotine shear machine, please feel free to contact us.We specialize in the production of guillotine shear machines of all types to your satisfaction. We also have Swing Beam Shearing Machine, Iron Worker, click here.
